The N2, N3 and N4 are capacitive, liquid based inclinometers with integrated sensor electronics. They are manufactured with an analog DC output. The sensor electronics require only minimal power and are in conjunction with the capacitive primary transformer characterized by high accuracy, a high signal-to-noise ratio and high long-term stability.

The measurement technique enables a linear relationship between the angle to be measured and the output signal. The determined angle is independent of the local gravitational acceleration, that means that no matter wher the measurement is being taken, whether in Europe, Australia, on Mount Everest or on the moon, the inclination will be measured correctly anywher.



Application



The inclinometers N2, N3 and N4 are suitable for applications requiring a small, light sensor for measurement of relatively large inclinations.

Typical areas of application include measuring instruments and inspection systems, vehicles, automation and safety engineering, scientific devices, medical and communications equipment as well as navigational systems.



Technical Specifications



Type N2 N3 N4

Measuring range ±10 degrees ±30 degrees ±70 degrees

Resolution <0,002 degrees <0,005 degrees <0,01 degrees

Linearity deviation 0,2% of measuring range

Transverse sensitivity <1% at 30° tilt

Settling time <0,3 seconds

Supply voltage Ub (regulated) 5 Volt

Permissible supply voltage range Ubz 3V ... 6V

Mechanical overload resistance 10 000 g (approx. 100 000 m/s2)

Current drawn at Ub = 5V approx.1mA

Degree of protection IP65

Operating temperature -40°C ... +85°C

Lagertemperatur -45°C ... +90°C

Weight (in metal housing without cable) 18,5 grams

Standard electrical connection 3 highly flexible, color-coded wires ?1mm, length approx. 18 cm (special lengths on request)

Alternative electrical connection 0,5m strong, flexible, shielded cable ?2,1mm (special lengths on request)

3 flexible, color-coded wires with Teflon insulation for extended temperature range

Values for analog DC output at UbN = 5 Volt

Sensitivity approx. 12mV/degree approx. 6mV/degree approx. 3.6mV/degree

Temperature drift of sensitivity -0,17% / K -0,12% / K

Temperature drift of zero point <±0,05mV/K <±0,025mV/K

Zero offset at Ub=5V (2,5±0,1)Volt - generally: 0,5Ub±4%

Output impedance 10 kOhm

On request: PWM-output



Each sensor will be delivered with individual calibration dates (offset and sensitivity)



Dimensions (in mm) and Connections

N2, N3, N4

Small Inclinometers for inclination measurement in the ranges of ±10, ±30 and ±70 degrees.

[+]

SEIKA front page

print version (pdf)

Features



linear output characteristics

high measurement accuracy

high long-term stability

hysteresis free output signal

minimal zero point drift

integrated sensor electronics

low power consumption

small housing

light weight

different output signal options

no interference by ambient electromagnetic fields

shockproof as without moving mechanical parts

hermetically sealed

sensor electrically isolated from point of measurement using high quality plastic housing - no ground connections

zero point adjustable through 360° using clamping ring

Description



The N2, N3 and N4 are capacitive, liquid based inclinometers with integrated sensor electronics. They are manufactured with an analog DC output. The sensor electronics require only minimal power and are in conjunction with the capacitive primary transformer characterized by high accuracy, a high signal-to-noise ratio and high long-term stability.

The measurement technique enables a linear relationship between the angle to be measured and the output signal. The determined angle is independent of the local gravitational acceleration, that means that no matter wher the measurement is being taken, whether in Europe, Australia, on Mount Everest or on the moon, the inclination will be measured correctly anywher.



Application



The inclinometers N2, N3 and N4 are suitable for applications requiring a small, light sensor for measurement of relatively large inclinations.

Typical areas of application include measuring instruments and inspection systems, vehicles, automation and safety engineering, scientific devices, medical and communications equipment as well as navigational systems.



Technical Specifications



Type N2 N3 N4

Measuring range ±10 degrees ±30 degrees ±70 degrees

Resolution <0,002 degrees <0,005 degrees <0,01 degrees

Linearity deviation 0,2% of measuring range

Transverse sensitivity <1% at 30° tilt

Settling time <0,3 seconds

Supply voltage Ub (regulated) 5 Volt

Permissible supply voltage range Ubz 3V ... 6V

Mechanical overload resistance 10 000 g (approx. 100 000 m/s2)

Current drawn at Ub = 5V approx.1mA

Degree of protection IP65

Operating temperature -40°C ... +85°C

Lagertemperatur -45°C ... +90°C

Weight (in metal housing without cable) 18,5 grams

Standard electrical connection 3 highly flexible, color-coded wires ?1mm, length approx. 18 cm (special lengths on request)

Alternative electrical connection 0,5m strong, flexible, shielded cable ?2,1mm (special lengths on request)

3 flexible, color-coded wires with Teflon insulation for extended temperature range

Values for analog DC output at UbN = 5 Volt

Sensitivity approx. 12mV/degree approx. 6mV/degree approx. 3.6mV/degree

Temperature drift of sensitivity -0,17% / K -0,12% / K

Temperature drift of zero point <±0,05mV/K <±0,025mV/K

Zero offset at Ub=5V (2,5±0,1)Volt - generally: 0,5Ub±4%

Output impedance 10 kOhm

On request: PWM-output



Each sensor will be delivered with individual calibration dates (offset and sensitivity)

NG2, NG3, NG4

Inclinometers of high measuring accuracy for inclination measurement in the ranges of ±10, ±30 and ±80 degrees with a non-amplified, non-conditioned output signal.

B_Sensor[+]

SEIKA front page

print version (pdf)

Features



linear output characteristics

high measurement accuracy

minimal linearity deviation

high long-term stability

hysteresis free output signal

minimal zero point drift

integrated sensor electronics

low power consumption

different output signal options

no interference by ambient electromagnetic fields

shockproof as without moving mechanical parts

hermetically sealed

sensor electrically isolated within the housing from point of measurement - no ground connections

zero point adjustable through 360° using clamping ring

Description



The NG2, NG3 and NG4 are capacitive, liquid based inclinometers with integrated sensor electronics. They are manufactured with an analog DC output. The sensor electronics require only minimal power and are in conjunction with the capacitive primary transformer characterized by high accuracy and high long-term stability.

The measurement technique enables a linear relationship between the angle to be measured and the output signal. The determined angle is independent of the local gravitational acceleration, that means that no matter wher the measurement is being taken, whether in Europe, Australia, on Mount Everest or on the moon, the inclination will be measured correctly anywher.



Application



The inclinometers NG2, NG3 and NG4 are suitable for applications requiring high measurement accuracy with low linearity deviations and high long-term stability for measurement of relatively large inclination angles.

Typical areas of application include construction, mining, vehicles, surveying equipment, aircraft, transportation and conveyor systems as well as ships.



Technical Specifications



Typ NG2 NG3 NG4

Measuring range ±10 degrees ±30 degrees ±80 degrees

Resolution <0.001 degrees <0.003 degrees <0.01 degrees

Linearity deviation <0.1% of measuring range

Transverse sensitivity <0.5% at 45° tilt

Settling time approx. 0.3 seconds

Mechanical overload resistance 10 000 g (approx. 100 000 m/s2)

Supply voltage UbN (regulated) 5V

Permissible supply voltage range Ubz 3V ... 6V

Current drawn at Ub = 5V approx.1mA

Degree of protection IP65

Operating temperature -40°C ... +85°C

Storage temperature -45°C ... +90°C

Weight (without clamping ring or cable) approx. 110 grams

Electrical connection 0.5m shielded cable ? 4.6mm

Values for analog DC output at UbN = 5 Volt



Sensitivity approx.10mV/degree approx.7mV/degree approx.4.5mV/degree

Temperature drift of sensitivity <-0.12%/K

Temperature drift of zero point <0.01mV/K

Zero offset at Ub=5V (2,5±0,1)Volt - generally: 0,5Ub±4%

Output impedance 10 kOhm

Dimensions (in mm) and Connections

NG2I, NG3I, NG4I

Inclinometers of high measurement accuracy with an integrated 4...20mA signal conditioner for inclination measurement in the ranges of ±10, ±30 and ±80 degrees

B_Sensor[+]

SEIKA front page

print version (pdf)

Features
